Trade
No
Type
|
Conductor
導體 |
Insulation
Material
Core
O.D. mm
|
Shields &
Material
|
Jacket
Material
|
Nom
Imp
(Ohm) |
|
AWG
|
Compos-
Ition
|
RG59/U
G2259 |
22 |
1/0.643
Bare
Copper
Covered
Steel
|
3.71
Polyethylene |
Bare
copper
Braid 95%
Shield
Coverage |
6.15
PVC
Black, white
|
75±3
|
RG59/U
G2059F |
20 |
1/0.813
Bare
Copper
|
3.71
Foam
Polyethylene |
Aluminum 40%
Tinned Copper
Braid 100%
Shield
Coverage |
6.15
PVC
Black, white |
75±3
|
RG59/U
GST59F |
22 |
7/0.254
Bare
Copper |
3.71
Foam
Polyethylene |
Bare
Copper
Braids
95% Shield
Coverage |
6.15
PVC
Matte Black,
Red, blue,
green
White |
75±3
|
RG59/U
G20598 |
20 |
1/0.813
Bare
Copper |
3.76
Foam
Polyethylene |
2Bare
Copper
Braids 95%
Shield Coverage
PVC Insulation
Between Braid |
8.00
PVC
Matte Black,
Red, Blue,
Gray,
Green |
75±3
|
RG122/U
G22122 |
22 |
7/0.127
Tinned
Copper |
22.44
Polyethylene |
Tinned Copper
Braids
95% Shield
Coverage |
4.06
Non-
Contaminating
PVC Black |
50±3
|
RG213/U
G13213 |
13 |
7/0.752
Bare
Copper |
7.24
Polyethylene |
Bare
Copper
Braids 97%
Shield Coverage |
10.29
Non-
Contaminating
PVC Black |
50±3
|
|
| |
|
| |
|
