Trade
No
Type
|
Conductor
導體 |
Insulation
Material
Core
O.D. mm |
Shields &
Material
|
Jacket
Material
|
Nom
Imp
(Ohm) |
| AWG
|
Compos-
Ition
|
RG6/U
G2106 |
21 |
1/0.724
Bare
Copper
Covered
Steel |
4.70
Polyethylene |
2 Bare Copper
Braid
97% Shield Coverage |
8.43
PVC
Black,
White
|
75±3
|
RG6/U
G1806F |
18 |
1/1.02
Bare
Copper |
4.57
Foam
Polyethylene |
Aluminum +40%
Tinned Copper Braid
100% Shield
Coverage |
6.86
PVC
Black,
white |
75±3
|
RG8/U
G1308 |
13 |
7/0.724
Bare
Copper |
7.24
Polyethylene |
Bare Copper
Braid
97%
Shield Coverage |
10.29
PVC
Black
|
52±3
|
RG8A/U
G1308A |
13 |
7/0.724
Bare
Copper |
7.24
Polyethylene |
Bare
Copper
Braid
97% Shield
Coverage |
10.29
Non-
Contaminating
PVC Black |
52±3
|
RG/9U
G1309 |
13 |
7/0.724
Bare
Copper
Covered
Steel |
7.11
Polyethylene |
2 Bare
Copper
Braid
97% Shield
Coverage |
10.67
Non-
contaminating
PVC Gray |
51±3
|
RG11/U
G1811 |
18 |
7/0.404
Bare
Copper |
7.24
Polyethylene |
Bare
Copper
Braids
97% Shield
Coverage |
10.29
Non-c
ontaminating
PVC Black |
75±3
|
RG11/U
G1411F |
14 |
1/1.63
Bare
Copper |
7.24
Foam
Polyethylene |
Aluminum
+40% Tinned
Copper Braid
100% Shield
Coverage
|
10.29
PVC
Black,
white |
75±3
|
