CM Rated 24 Gage
|
|
individually shielded
|
|
| |
|
Insulation Construction
|
Trade
NO |
NO
Pairs |
Outer
Jacket
Thickness
mm |
Nominal
O.D
Mm |
Tinned copper 7/0.203
Polyolefin insulated ID:1.02mm.
Pairs color coded Red & Black.
Each pair individually shielded
with aluminum-polyester shield.
Overall paper tape wrap.
Overall black matte PVC jacket
with nylon ripcord.
Nom.D.C.R.:92.13Ω
KM
Nom.Capacitance:102 PF/M |
AS02402 |
2 |
1.02 |
4.04 |
| AS02404 |
4 |
1.20 |
7.32 |
| AS02406 |
6 |
1.20 |
9.02 |
| AS02408 |
8 |
1.50 |
9.85 |
| AS02412 |
12 |
1.50 |
11.50 |
| AS02416 |
16 |
1.60 |
12.78 |
| AS02420 |
20 |
1.60 |
13.76 |
| AS02424 |
24 |
1.60 |
15.44 |
| AS02426 |
26 |
1.60 |
16.03 |
| AS02428 |
28 |
1.80 |
16.50 |
| AS02432 |
32 |
1.80 |
16.70 |
| AS02436 |
36 |
1.80 |
17.60 |
| AS02448 |
48 |
2.03 |
20.30 |
| AS02452 |
52 |
2.03 |
20.73 |
| AS02456 |
56 |
2.03 |
21.95 |
|
| |
|
| |
|
